Reticle Ruler 0.220" 40 Divisions
Reticle Ruler 0.220" 40 Divisions
Reticle Ruler 0.220" 40 Divisions

Reticle Ruler 0.220" 40 Divisions

No reviews yet Write a Review
KR-296 Ruler reticle 0.220" in 40 divisions. Numbered 0.020" / 0.001" divisions and 0.200" / 0.010" divisions. Learn how to make accurate measurements when usin… Read more
SKU: KR296
Measurement: Inches
$125.00
icon Share icon Share
Request a quote
Description

KR-296 Ruler reticle 0.220" in 40 divisions. Numbered 0.020" / 0.001" divisions and 0.200" / 0.010" divisions. Learn how to make accurate measurements when using your reticle here and learn about calibrating your microscope here. Reticle is available in a number of different diameters; select when ordering.

  • Divisions: 0.020" / 0.001" divisions and 0.200" / 0.010"
  • Lines: Chrome deposition
  • Line width: All line widths are 0.0005" - 0.0007"
  • Height of major divisions: 0.0125"
  • Height of mid divisions: 0.008"
  • Height of minor divisions: 0.006"
  • All tolerances unless otherwise stated: ± 0.0002"
  • Flatness: 2 waves or better
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
