Reticle Grid 7mm Squares 49 Total
Reticle Grid 7mm Squares 49 Total
Reticle Grid 7mm Squares 49 Total

Reticle Grid 7mm Squares 49 Total

No reviews yet Write a Review
KR-492 glass eyepiece reticle. Grid 7mm x 7mm. 49 squares total (7 x 7) 1mm squares. Without numbers and letters. Diagonal equals 9.89mm. Available in a variety… Read more
SKU: KR492
Square Size: 1mm
Measurement: Metric
$125.00
icon Share icon Share
Request a quote
Description

KR-492 glass eyepiece reticle. Grid 7mm x 7mm. 49 squares total (7 x 7) 1mm squares. Without numbers and letters. Diagonal equals 9.89mm. Available in a variety of diameters, select when ordering.

  • Each Square: 1mm x 1mm when using 1x objective
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Glass Thickness: 1.5mm+/-0.2mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
