Reticle Grid 0.5mm Squares 1,600 Total Labeled
Reticle Grid 0.5mm Squares 1,600 Total Labeled
Reticle Grid 0.5mm Squares 1,600 Total Labeled

Reticle Grid 0.5mm Squares 1,600 Total Labeled

No reviews yet Write a Review
KR-454 glass eyepiece reticle. Grid 20mm x 20mm. 1,600 squares total (40x40). Diagonal = 28.28mm. Labeled with numbers vertical (1-40) and letters horizontal (A… Read more
SKU: KR454
Measurement: Metric
Square Size: 0.5mm
$125.00
icon Share icon Share
Request a quote
Description

KR-454 glass eyepiece reticle. Grid 20mm x 20mm. 1,600 squares total (40x40). Diagonal = 28.28mm. Labeled with numbers vertical (1-40) and letters horizontal (A-NN). Available in a variety of diameters, select below when ordering.

  • Each Square: 0.5mm when using 1x objective
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Glass Thickness: 1.5mm+/-0.2mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
