Reticle 8 Concentric Circles 0.05 - 0.40 Inch
Reticle 8 Concentric Circles 0.05 - 0.40 Inch
Reticle 8 Concentric Circles 0.05 - 0.40 Inch

Reticle 8 Concentric Circles 0.05 - 0.40 Inch

No reviews yet Write a Review
KR-514 Concentric circles reticle (8 circles) with diameters equal 0.05" - 0.40" with crossline. No numbers. Learn how to make accurate measurements when using … Read more
SKU: KR514
Measurement: Inches
$125.00
icon Share icon Share
Request a quote
Description

KR-514 Concentric circles reticle (8 circles) with diameters equal 0.05" - 0.40" with crossline. No numbers. Learn how to make accurate measurements when using your reticle here and learn about calibrating your microscope here. Reticle is available in a number of different diameters, select below when ordering.


  • Diameters: 0.05", 0.10", 0.15", 0.20", 0.25", 0.30", 0.35", 0.40"
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Tolerances: Unless otherwise stated +/-0.0002" (+/-5 microns)
  • Glass Thickness: 1.5mm+/-0.1mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.



NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
