Reticle 30 Concentric Circles 0.015 - 0.450 Inch
Reticle 30 Concentric Circles 0.015 - 0.450 Inch
Reticle 30 Concentric Circles 0.015 - 0.450 Inch

Reticle 30 Concentric Circles 0.015 - 0.450 Inch

No reviews yet Write a Review
KR-516 Concentric circles reticle (30 circles) with diameters equal 0.015" - 0.450" with crossline. Numbered 0-15 every 2nd circle. Learn how to make accurate m… Read more
SKU: KR516
Measurement: Inches
$125.00
icon Share icon Share
Request a quote
Description

KR-516 Concentric circles reticle (30 circles) with diameters equal 0.015" - 0.450" with crossline. Numbered 0-15 every 2nd circle. Learn how to make accurate measurements when using your reticle here and learn about calibrating your microscope here. Reticle is available in a number of different diameters, select below when ordering.


  • Diameters: 0.015" - 0.450"
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Tolerances: Unless otherwise stated +/-0.0002" (+/-5 microns)
  • Glass Thickness: 1.5mm+/-0.1mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.



NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
