Ball Bearing Clamping Microscope Stand

This microscope ball bearing boom stand has a table clamp to attach it to the edge of a work table. Dimensions are as follows:

• Vertical post height: 15.1" (384mm) - Extension post is available here.
• Vertical post diameter: 37.2mm
• Horizontal arm length: 22.4" (570mm)
• Horizontal arm diameter: 20mm
• Horizontal arm travel distance on Z-Axis: 11.1" (282mm)
• Clamping mechanism dimensions: 140 x 70 x 65mm
• Weight: 22 lbs
• Dimensions: 22.4 x 11.2 x 15.9" (570 x 285 x 405mm)
• Mounting post: your choice of 20mm, 25mm, or 32mm, or no arbor (5/8" mounting pin opening)
