Reticle Crossed Scale 0.100 Inch 100 Divisions
Reticle Crossed Scale 0.100 Inch 100 Divisions
Reticle Crossed Scale 0.100 Inch 100 Divisions

Reticle Crossed Scale 0.100 Inch 100 Divisions

No reviews yet Write a Review
KR-634 Crossed scale reticle 0.100" in 100 divisions. Numbered 50-0-50. Learn how to make accurate measurements when using your reticle here and learn about cal… Read more
SKU: KR634
Measurement: Inches
$125.00
icon Share icon Share
Request a quote
Description

KR-634 Crossed scale reticle 0.100" in 100 divisions. Numbered 50-0-50. Learn how to make accurate measurements when using your reticle here and learn about calibrating your microscope here. Reticle is available in a number of different diameters, select below when ordering.

  • Divisions: 0.001" with 1x objective.
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Tolerances: Unless otherwise stated +/-0.0002" (+/-5 microns)
  • Glass Thickness: 1.5mm+/-0.1mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.



NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
